10K GD Trailer Axle Hub - 8 lug (New Style)

  • 9-10KGD Trailer Axle Hub - 8 lug (New Style) - The Trailer Parts Outlet
  • 9-10KGD Trailer Axle Hub - 8 lug (New Style) - The Trailer Parts Outlet
  • 12K-16K Trailer Axle Hydraulic Drum Brake Assembly - 12.25"x5" - 12000-16000 lb Capacity - Right Hand (Passenger Side).
  • 9-10KGD Trailer Axle Hub - 8 lug (New Style) - The Trailer Parts Outlet
  • 9-10KGD Trailer Axle Hub - 8 lug (New Style) - The Trailer Parts Outlet
  • 10K GD Trailer Axle Hub - 8 lug (New Style)
1 5

10K GD Trailer Axle Hub - 8 lug (New Style)

10K GD Trailer Axle Hub - 8 lug (New Style)

SKU : 0910GDHUB865BARE-TK-NEWSTYLE

Online price only

$180

Online price only

SAVE 0% (833) 910-3416
4.5
Rated 4.5 out of 5 stars
101 Reviews
Shipping: Calculated at Checkout
Hub Options:
Tax Exempt? Enter info in cart when you're done shopping.
View full details
  • Product Information
  • Reviews

General Duty Hub Only Specs:

  • General Duty Hub Only
  • 8 on 6.5" Bolt Pattern
  • 1 - 25520 Outer Race (Already Pressed In) 3.265" OD
  • 1 - 382A Inner Race (Already Pressed In) 3.813" OD
  • Uses 25580 (1.75" ID) and 387A (1.25" OD) bearings (sold separately)
  • 5,000lb Capacity Per Hub
  • Drum sold separately
  • 5/8 Wheel Studs
  • This hub is NOT COMPATIBLE with Texas Pride or Rockwell Axles

General Duty Hub Assembly Specs:

  • General Duty Hub
  • 8 on 6.5" Bolt Pattern
  • 1 - 25520 Outer Race (Already Pressed In) 3.265" OD
  • 1 - 382A Inner Race (Already Pressed In) 3.813" OD
  • 1 - 25580 Outer Bearing 1.75" ID
  • 1 - 387A Inner Bearing 2.250 OD
  • 1 - 10-51 Oil Seal 2.875" ID/3.880" OD
  • 1 - 21-88 Oil Cap
  • 8 - Cone Wheel Lug Nuts
  • 5/8" Wheel Studs

Features:

  • Hub kit with 8 on 6.5" Bolt Pattern For 10,000 lb General Duty Axles Manufactured After 05/2013
  • The races are pre-pressed for your convenience
  • This hub is designed for use with 10K General Duty axle spindles
  • Each hub has a capacity if 5,000lbs
  • Spindle nut, washer and drum sold separately
  • This hub is NOT COMPATIBLE with Texas Pride or Rockwell Axles
